HIF-1 alpha Antibody


Western Blot: HIF-1 alpha Antibody [NBP1-02160] - Detection of HIF-1 alpha using NBP1-02160. Lane 1: COS7 CoCl treated cells Lane 2: COS7 untreated cells.
Simple Western: HIF-1 alpha Antibody [NBP1-02160] - Simple Western lane view shows a specific band for HIF-1 alpha in 0.5 mg/ml of Hypoxic HeLa lysate. This experiment was performed under reducing conditions using the ...read more

Product Details

Reactivity Hu, Mu, Po, Bovine, Rabbit, MonkeySpecies Glossary
Applications WB, Simple Western
0.2 mg/ml

HIF-1 alpha Antibody Summary

Genomic sequence made to an internal portion of human HIF-1 alpha (within amino acids 400 - 550) [Swiss-Prot# Q16665].
Predicted Species
Monkey (100%), Bovine (96%), Rabbit (94%). Backed by our 100% Guarantee.
Immunogen affinity purified
Innovator's Reward
Test in a species/application not listed above to receive a full credit towards a future purchase.

Packaging, Storage & Formulations

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
PBS, 0.1% BSA, and 50% Glycerol
0.05% Sodium Azide
0.2 mg/ml
Immunogen affinity purified


  • Western Blot 1:3500
  • Simple Western 1:250
Application Notes
In WB, the bands are seen ~97 kDa and 120 kDa. In Simple Western only 10 - 15 ul of the recommended dilution is used per data point.
Theoretical MW
93 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Reviewed Applications
Read 2 Reviews rated 3.5
NBP1-02160 in the following applications:

Read Publications using
NBP1-02160 in the following applications:

  • WB
    3 publications

Reactivity Notes

Immunogen sequence has 89% homology to Chicken. Mouse and Porcine reactivities were reported by a customer review.

Alternate Names for HIF-1 alpha Antibody

  • ARNT-interacting protein
  • Basic-helix-loop-helix-PAS protein MOP1
  • BHLHE78
  • Class E basic helix-loop-helix protein 78
  • HIF1 alpha
  • HIF-1 alpha
  • HIF1A
  • HIF-1-alpha
  • HIF1-alpha
  • hypoxia inducible factor 1, alpha subunit (basic helix-loop-helix transcriptionfactor)
  • hypoxia-inducible factor 1-alpha
  • Member of PAS protein 1
  • member of PAS superfamily 1
  • PAS domain-containing protein 8
  • PASD8alpha subunit (basic helix-loop-helix transcriptionfactor)


HIF1 (hypoxia-inducible factor 1), a heterodimeric transcription factor complex central to cellular response to hypoxia, consists of two subunits (HIF-1 alpha and HIF-1 beta) which are basic helix-loop-helix proteins of the PAS (Per, ARNT, Sim) family. Expression of HIF-1 alpha protein is regulated by cellular oxygen level alterations as well as in oxygen-independent manner via different cytokines (through the PI3K-AKT-mTOR pathway), growth factors, oncogenic activation, or loss of tumor suppressor function etc. In normoxic cells, HIF-1 alpha is proline hydroxylated leading to a conformational change that promotes its binding to the VHL (von Hippel Lindau) protein E3 ligase complex; ubiquitination and followed by rapid proteasomal degradation. Hypoxia as well as chemical hydroxylase inhibitors (desferrioxamine, cobalt etc.) inhibit HIF-1 alpha degradation and lead to its accumulation in the cells, whereas, contrastingly, HIF-1 beta/ARNT (AhR nuclear translocator) remains stable under both conditions. Besides their critical role in hypoxic response, HIF1s regulates the transcription of genes responsible for angiogenesis, erythropoiesis/iron-metabolism, glucose metabolism, cell proliferation/survival, adipogenesis, carotid body formation, B lymphocyte development and immune reactions.


This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Customers Who Viewed This Item Also Viewed...

Species: Hu, Mu, Rt, Ca
Applications: WB, ELISA, ICC/IF, IHC, IHC-Fr, IHC-P
Species: Hu
Applications: ICC/IF, IHC, IHC-P
Species: Hu, Mu, Rt, Bv, Ft, Pm, Sh
Applications: WB, ChIP, GS, ICC/IF, IHC, IHC-P, IP
Species: Hu
Applications: Func, PAGE
Species: Hu
Applications: WB, IP
Species: Hu, Mu, Rt, Fi, Ha, Pm, Sh
Applications: WB, Simple Western, ChIP, ELISA, Flow, GS, ICC/IF, IHC, IHC-Fr, IHC-P, IP
Species: Hu, Mu
Applications: WB, IHC, IHC-P
Species: Hu, Mu
Applications: WB, ChIP, Flow, ICC/IF, IHC, IHC-Fr
Species: Hu, Mu, Rt, Ca, Pl
Applications: WB, Simple Western, ELISA, Flow, GS, ICC/IF, IHC, IHC-Fr, IHC-P, ChIP
Species: Hu, Mu, Rt, Ye, Xp(-)
Applications: WB, ELISA, Flow, ICC/IF, IHC, IHC-Fr, IHC-P, IP
Species: Hu, Mu, Rt
Applications: WB, IHC, IHC-P
Species: Hu, Rt, Ca, Mk
Applications: WB, IHC, IHC-P, IP
Species: Hu, Mu, Rt
Applications: WB, ICC/IF, IHC, IHC-P
Species: Hu, Mu, Rt, Po, Bv, Ft, Mk, Pm, Rb, Sh, Xp, Ye
Applications: WB, ChIP, ELISA, Flow, GS, ICC/IF, IHC, IHC-Fr, IHC-P, IP, TCS, LA
Species: Hu, Mu, Rt, Po, Av, Fe, Fi, Rb, Xp
Applications: WB, ICC/IF, IHC, IHC-P
Species: Hu, Mu, Mk
Applications: WB, ICC/IF, IHC, IHC-P
Species: Hu, Mu, Rt
Applications: WB, ICC/IF, IHC, IHC-Fr, IHC-P, IHC-FrFl
Species: Hu, Mu, Rt, Pm
Applications: WB, Simple Western, Flow, ICC/IF, IHC, IHC-P, IP

Publications for HIF-1 alpha Antibody (NBP1-02160)(4)

Reviews for HIF-1 alpha Antibody (NBP1-02160) (2) 3.52

Average Rating: 3.5
(Based on 2 reviews)
We have 2 review tested in 1 species: Mouse.
We have 2 review tested in 1 application: WB.

Reviews using NBP1-02160:
Filter by Applications
All Applications
Filter by Species
All Species
Images Ratings Applications Species Date Details
Western Blot HIF-1 alpha NBP1-02160
reviewed by:
WB 01/31/2013


ApplicationWestern Blot
Special ApplicationsTested in mouse intestine, Porcine (brain, liver and intestine). Human cell lines as CacO-2, IMR32 and HUVEC
Pub Med ID23203207
reviewed by:
WB Mouse 03/20/2009


ApplicationWestern Blot
Sample TestedMouse Heart Tissue, Sample Amount: 100 ug


Blocking DetailsBlocking Buffer: 5% milk, Blocking Time: 1 hour, Blocking Temp: 25 degrees Celsius

Primary Anitbody

Dilution RatioPrimary Ab Dilution Ratio: 1/3000, Primary Ab Incubation Dilution Buffer: 5% BSA, Incubation Time: 16 hr, Incubation Temp: 4C

Secondary Antibody

Secondary DescriptionSecondary Ab: donkey mAb, Secondary Ab Dilution Ratio: 1/3000


Detection NotesExposure Time: 1 hour, Non-Specific Bands: 64-98 kDa

Product General Protocols

View specific protocols for HIF-1 alpha Antibody (NBP1-02160): Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

Video Protocols

WB Video Protocol

FAQs for HIF-1 alpha Antibody (NBP1-02160). (Showing 1 - 5 of 5 FAQs).

  1. Why is there a difference between the theoretical MW for HIF1A and the observed MW for HIF-1 alpha?
    • HIF1A, like many other proteins, has post-translational modifications. Depending on the size, amount and nature of the post-translational modifications, it can cause subtle to very large changes in molecular weight.
  2. Which antibody(ies) do you recommend for the detection of HIF-1a by immunohistochemistry in the sections of paraffin-embedded mouse liver samples? I would appreciate if you can give me several choices and rank them in the order of performance. My goal is to distinguish HIF upregulation by prolyl hydroxylase inhibitor in different liver cells.
    • All of our antibodies are of high quality and are well tested/validated in species/applications we list on the datasheet. However, as desired by you, I am suggesting you four HIF-1 alpha antibodies based upon customer reviews, as well as the number of peer reviewed publications in which these products has been cited by researchers from reputed institutes. (1) HIF-1 alpha Antibody (H1alpha67) (cat# NB100-105) (cited in at least 218 peer reviewed publications) (2) HIF-1 alpha Antibody (cat# NB100-479) (cited in at least 51 peer reviewed publications) (3) HIF-1 alpha Antibody (H1alpha67) (cat# NB100-123 ) (cited in at least 38 peer reviewed publications) (4) HIF-1 alpha Antibody (cat# NB100-449 ) (cited in at least 31 peer reviewed publications).
  3. I would like to know, does it exist path for detection HIF 1 in the venous blood before and after revascularization of the leg?
    • We are not entirely sure if HIF-1 alpha will be present in the leg after revascularization. It may be present but you may want to search the literature to see if this has been looked at before. If not, then this would certainly be an experiment worth doing.
  4. What is the molecular weight (kDa) of protein HIF 1 alpha in western blot?
    • The theoretical molecular weight of HIF 1-alpha is ~93kDa, however, you will likely see a band between 100-120kDa due to phosphorylation.
  5. What do you mean with HIF-1 alpha unprocessed?
    • The unprocessed refers to the unregulated undegraded full length protein that is detected with treatment, but not post translationally modified and phosphorylated. The PTM protein is expressed at the higher molecular weight.
