Endoglin/CD105 Antibody [Unconjugated]

Images


Endoglin/CD105 was detected in immersion fixed frozen sections of mouse embryo (E13-15) using Goat Anti-Mouse Endoglin/CD105 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1320) at 15 µg/mL overnight at 4 ...read more
Simple Western lane view shows lysates of bEnd.3 mouse endothelioma cell line, loaded at 0.2 mg/mL. A specific band was detected for Endoglin/CD105 at approximately 121 kDa (as indicated) using 5 µg/mL of Goat ...read more
Western blot shows lysates of bEnd.3 mouse endothelioma cell line and MS‑1 mouse pancreatic islet endothelial cell line. PVDF membrane was probed with 0.5 µg/mL of Goat Anti-Mouse Endoglin/CD105 Antigen ...read more
Endoglin/CD105 was detected in immersion fixed MS-1 mouse pancreatic islet endothelial cell line using Goat Anti-Mouse Endoglin/CD105 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1320) at 10 µg/mL for 3 ...read more
Endoglin/CD105 was detected in immersion fixed rat mesenchymal stem cells using Goat Anti-Mouse Endoglin/CD105 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1320) at 10 µg/mL for 3 hours at room ...read more

Product Details

Summary
Reactivity MuSpecies Glossary
Applications WB, Simple Western, Flow, IHC, CyTOF-ready, ICC/IF
Clonality
Polyclonal
Host
Goat
Conjugate
Unconjugated
Concentration
LYOPH

Order Details

View Available Conjugates
Catalog# & Conjugate Size Price
View Available Formulations
Catalog# & Formulation Size Price

Endoglin/CD105 Antibody [Unconjugated] Summary

Immunogen
Mouse myeloma cell line NS0-derived recombinant mouse Endoglin/CD105
Glu27-Gly581
Accession # Q8K100
Specificity
Detects mouse Endoglin in direct ELISAs and Western blots. In direct ELISAs, less than 20% cross-reactivity with recombinant rat Endoglin is observed and less than 5% cross-reactivity with recombinant human Endoglin is observed.
Source
N/A
Isotype
IgG
Clonality
Polyclonal
Host
Goat
Gene
ENG
Innovator's Reward
Test in a species/application not listed above to receive a full credit towards a future purchase.

Applications/Dilutions

Dilutions
  • Western Blot 0.5 ug/mL
  • Simple Western 5 ug/mL
  • Flow Cytometry 2.5 ug/10^6 cells
  • Immunohistochemistry 5-15 ug/mL
  • CyTOF-ready
  • Immunocytochemistry 5-15 ug/mL
Reviewed Applications
Read 2 Reviews rated 4.5
using
AF1320 in the following applications:

Publications
Read Publications using
AF1320 in the following applications:

Packaging, Storage & Formulations

Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Buffer
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.
Preservative
No Preservative
Concentration
LYOPH
Reconstitution Instructions
Reconstitute at 0.2 mg/mL in sterile PBS.

Notes

This product is produced by and ships from R&D Systems, Inc., a Bio-Techne brand.

Alternate Names for Endoglin/CD105 Antibody [Unconjugated]

  • CD105 antigen
  • CD105
  • Endoglin
  • ENDOsler-Rendu-Weber syndrome 1
  • ENG
  • HHT1FLJ41744
  • ORW
  • ORW1

Background

Endoglin (CD105) is a 90 kDa type I transmembrane glycoprotein of the zona pellucida (ZP) family of proteins (1-3). Endoglin and betaglycan/T beta RIII are type III receptors for TGF beta superfamily ligands, sharing 71% amino acid (aa) identity within the transmembrane (TM) and cytoplasmic domains. Endoglin is highly expressed on proliferating vascular endothelial cells, chondrocytes, and syncytiotrophoblasts of term placenta, with lower amounts on hematopoietic, mesenchymal and neural crest stem cells, activated monocytes, and lymphoid and myeloid leukemic cells (2-5). Mouse Endoglin cDNA encodes 653 aa including a 26 aa signal sequence, a 555 aa extracellular domain (ECD) with an orphan domain and a two-part ZP domain, a TM domain, and a 47 aa cytoplasmic domain (1-3). A mouse isoform with a 35 aa cytoplasmic domain (S-endoglin) can oppose effects of long (L) Endoglin (6, 7). The mouse Endoglin ECD shares 69%, 84%, 62%, 63%, and 66% aa identity with human, rat, bovine, porcine, and canine Endoglin, respectively. Endoglin homodimers interact with TGF-beta 1 and TGF-beta 3 (but not TGF-beta 2) but only after binding T beta RII (8). Similarly, they interact with activin-A and BMP-7 via activin type IIA or B receptors, and with BMP-2 via BMPR-1A/ALK-3 or BMPR-1B/ALK-6 (9). BMP-9, however, is reported to bind Endoglin directly (10). Endoglin modifies ligand-induced signaling in multiple ways. For example, expression of Endoglin can inhibit TGF-beta 1 signals but enhance BMP7 signals in the same myoblast cell line (11). In endothelial cells, Endoglin inhibits T beta RI/ALK5, but enhances ALK1-mediated activation (12). Deletion of mouse Endoglin causes lethal vascular and cardiovascular defects, and human Endoglin haploinsufficiency can a cause the vascular disorder, hereditary hemorrhagic telangiectasia type I (13, 14). These abnormalities confirm the essential function of Endoglin in differentiation of smooth muscle, angiogenesis, and neovascularization (2-4, 12-14). In preeclampsia of pregnancy, high levels of proteolytically generated soluble Endoglin and VEGF R1 (sFlt-1), along with low placental growth factor (PlGF), are pathogenic due to antiangiogenic activity (15).

  1. Ge, A.Z. and E.C. Butcher (1994) Gene 138:201.
  2. ten Dijke, P. et al. (2008) Angiogenesis 11:79.
  3. Bernabeu, C. et al. (2007) J. Cell. Biochem. 102:1375.
  4. Mancini, M.L. et al. (2007) Dev. Biol. 308:520.
  5. Moody, J.L. et al. (2007) Stem Cells 25:2809.
  6. Velasco, S. et al. (2008) J. Cell Sci. 121:913.
  7. Perez-Gomez, E. et al. (2005) Oncogene 24:4450.
  8. Cheifetz, S, et al. (1992) J. Biol. Chem. 267:19027.
  9. Barbara, N.P. et al. (1999) J. Biol. Chem. 274:584.
  10. Scharpfenecker, M. et al. (2007) J. Cell Sci. 120:964.
  11. Scherner, O. et al. (2007) J. Biol. Chem. 282:13934.
  12. Pece-Barbara, N. et al. (2005) J. Biol. Chem. 280:27800.
  13. Arthur, H.M. et al. (2000) Dev. Biol. 217:42.
  14. Lebrin, F. and C.L. Mummery (2008) Trends Cardiovasc. Med. 18:25.
  15. Venkatesha, S. et al. (2006) Nat. Med. 12:642.

Limitations

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Customers Who Viewed This Item Also Viewed...

AF-386-PB
Species: Hu
Applications: WB, Flow, CyTOF-ready, ICC
NBP1-84550
Species: Hu
Applications: WB, IHC, IHC-P
NB100-524
Species: Hu, Mu
Applications: WB, Flow, ICC/IF, IHC, IHC-P, IP, Flow-IC
370-AL
Species: Hu
NB600-1071
Species: Mu, Rt
Applications: WB, ELISA, Flow, ICC/IF, IHC, IHC-Fr, IHC-P, IP
AF3628
Species: Mu, Rt
Applications: WB, Flow, IHC, CyTOF-ready, ICC
NB110-41083
Species: Hu
Applications: WB, ChIP, ELISA
NB100-77417
Species: Mu
Applications: WB, Flow, ICC/IF, IHC, IHC-Fr, IHC-P, IP, In vivo, CyTOF-ready
AF2067
Species: Hu, Po, Ca
Applications: WB, Flow, IHC, CyTOF-ready, ICC
NBP1-47386
Species: Hu, Mu, Rb(-)
Applications: WB, ELISA, Flow, ICC/IF, IHC, IHC-P, Flow-IC
NBP1-85740
Species: Hu, Po
Applications: WB, ICC/IF, IHC, IHC-P
NBP2-36561
Species: Hu, Mu
Applications: WB, B/N, ELISA, Flow, ICC/IF, IHC-Fr, IP
NBP2-56244
Species: Hu
Applications: WB, ICC/IF
AF321
Species: Hu
Applications: WB, Flow, IHC, Block, CyTOF-ready
AF1172
Species: Hu, Mu, Rt, Ca
Applications: WB, Simple Western, Flow, IHC, CyTOF-ready, ICC
NBP1-33050
Species: Hu, Mu
Applications: WB, ICC/IF, IHC, IHC-P

Publications for Endoglin/CD105 Antibody (AF1320)(11)

We have publications tested in 2 confirmed species: Human, Mouse.

We have publications tested in 5 applications: IF, IHC, IHC - Not specified, IHC Paraffin-embedded, IHC-OCT embedded.


Filter By Application
IF
(1)
IHC
(6)
IHC - Not specified
(1)
IHC Paraffin-embedded
(2)
IHC-OCT embedded
(1)
All Applications
Filter By Species
Human
(2)
Mouse
(9)
All Species
Showing Publications 1 - 10 of 11. Show All 11 Publications.
Publications using AF1320 Applications Species
DL Coutu, KD Kokkaliari, L Kunz, T Schroeder Multicolor quantitative confocal imaging cytometry Nat. Methods, 2018;15(1):39-46. 2018 [PMID: 29320487] (IHC,, Mouse) IHC Mouse
M Wroblewski, R Bauer, M Cubas Córd, F Udonta, I Ben-Batall, K Legler, C Hauser, J Egberts, M Janning, J Velthaus, C Schulze, K Pantel, C Bokemeyer, S Loges Mast cells decrease efficacy of anti-angiogenic therapy by secreting matrix-degrading granzyme B Nat Commun, 2017;8(1):269. 2017 [PMID: 28814715] (IHC,, Mouse) IHC Mouse
EM Palmieri, A Menga, R Martín-Pér, A Quinto, C Riera-Domi, G De Tullio, DC Hooper, WH Lamers, B Ghesquière, DW McVicar, A Guarini, M Mazzone, A Castegna Pharmacologic or Genetic Targeting of Glutamine Synthetase Skews Macrophages toward an M1-like Phenotype and Inhibits Tumor Metastasis Cell Rep, 2017;20(7):1654-1666. 2017 [PMID: 28813676] (IHC,, Mouse) IHC Mouse
N García-Rom, J Carrión-Na, S Esteban-Ru, E Lázaro-Ibá, M Peris-Celd, MM Alonso, J Guzmán-De-, C Fernández-, AO de Mendivi, S García-Duq, C Escobedo-L, R Prat-Acín, C Belda-Inie, A Ayuso-Saci DNA sequences within glioma-derived extracellular vesicles can cross the intact blood-brain barrier and be detected in peripheral blood of patients Oncotarget, 2017;8(1):1416-1428. 2017 [PMID: 27902458] (IHC,, Mouse) IHC Mouse
PI3 kinase inhibition improves vascular malformations in mouse models of hereditary haemorrhagic telangiectasia Nat Commun, 2016;7(0):13650. 2016 [PMID: 27897192] (IHC,, Mouse) IHC Mouse
Stimac M, Dolinsek T, Lampreht U, Cemazar M, Sersa G Gene Electrotransfer of Plasmid with Tissue Specific Promoter Encoding shRNA against Endoglin Exerts Antitumor Efficacy against Murine TS/A Tumors by Vascular Targeted Effects. PLoS ONE, 2015;10(4):e0124913. 2015 [PMID: 25909447] (IHC Paraffin-embedded,, Mouse) IHC Paraffin-embedded Mouse
Grafton K, Moir L, Black J, Hansbro N, Hansbro P, Burgess J, Oliver B LF-15 & T7, synthetic peptides derived from tumstatin, attenuate aspects of airway remodelling in a murine model of chronic OVA-induced allergic airway disease. PLoS ONE, 2014;9(1):e85655. 2014 [PMID: 24454912] (IHC - Not specified,, Human) IHC - Not specified Human
Jimenez V, Munoz S, Casana E, Mallol C, Elias I, Jambrina C, Ribera A, Ferre T, Franckhauser S, Bosch F In vivo adeno-associated viral vector-mediated genetic engineering of white and brown adipose tissue in adult mice. Diabetes, 2013;62(12):4012-22. 2013 [PMID: 24043756] (IHC,, Mouse) IHC Mouse
Dolinsek T, Markelc B, Sersa G, Coer A, Stimac M, Lavrencak J, Brozic A, Kranjc S, Cemazar M Multiple delivery of siRNA against endoglin into murine mammary adenocarcinoma prevents angiogenesis and delays tumor growth. PLoS ONE, 2013;8(3):e58723. 2013 [PMID: 23593103] (IF,, Human) IF Human
Park S, Wolfram P, Canty K, Harley B, Nombela-Arrieta C, Pivarnik G, Manis J, Beggs H, Silberstein L Focal adhesion kinase regulates the localization and retention of pro-B cells in bone marrow microenvironments. J Immunol, 2013;190(3):1094-102. 2013 [PMID: 23264658] (IHC-OCT embedded,, Mouse) IHC-OCT embedded Mouse
Show All 11 Publications.

Reviews for Endoglin/CD105 Antibody (AF1320) (2) 4.52

Average Rating: 4.5
(Based on 2 reviews)
We have 2 reviews tested in 1 species: Mouse.

Reviews using AF1320:
Filter by Applications
IF
(2)
All Applications
Filter by Species
Mouse
(2)
All Species
Images Ratings Applications Species Date Details

reviewed by:
Anonymous
IF Mouse 01/05/2015
View

Summary

ApplicationImmunofluorescence
Sample TestedSee PMID 23593103
SpeciesMouse

Blocking

Blocking DetailsSee PMID 23593103

Details

Detection NotesSee PMID 23593103

Comments

CommentsSee PMID 23593103

reviewed by:
Anonymous
IF Mouse 01/05/2015
View

Summary

ApplicationImmunofluorescence
Sample TestedSee PMID 21060150
SpeciesMouse

Blocking

Blocking DetailsSee PMID 21060150

Details

Detection NotesSee PMID 21060150

Comments

CommentsPublished PMID 21060150

Product General Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

Video Protocols

WB Video Protocol

FAQs for Endoglin/CD105 Antibody (AF1320). (Showing 1 - 2 of 2 FAQs).

  1. I wonder if you have a CD105 or CD34 antibody suitable for IHC that is specific for human and do not bind mouse?
    • We do not have any anti-human CD34 or CD105 antibodies that are confirmed to NOT detect the mouse protein. When we have tested an antibody and confirmed that it will not react with mouse samples, we will add Mu(-) to the datasheet, and unfortunately all of our CD105 and CD34 antibodies will either detect the mouse protein, or they have not been used in mouse samples before.
  2. We are interested in CD105 antibodies that could react with dog, please let me know which products in your catalog you would recommend.
    • We do not currently carry any CD105 antibodies that have been validated for use in dog samples. However, if you are interested in testing any of our CD105 antibodies with dog samples you would be eligible for our Innovators Reward Program, in which you can get a discount voucher for the purchase price of the product. Please contact us at innovators@novusbio.com with any questions regarding this program.

Secondary Antibodies



Isotype Controls

Additional Endoglin/CD105 Products

Bioinformatics Tool for Endoglin/CD105 Antibody (AF1320)

Discover related pathways, diseases and genes to Endoglin/CD105 Antibody (AF1320). Need help? Read the Bioinformatics Tool Guide for instructions on using this tool.
