ATM Antibody (2C1)


Western Blot: ATM Antibody (2C1) [NB100-309] - HeLa whole cell and nuclear extracts (30 ug) were separated by 5% SDS-PAGE, and the membrane was blotted with ATM antibody (2C1) [NB100-309] diluted at 1:1000. Theoretical more
Immunohistochemistry-Paraffin: ATM Antibody (2C1) [NB100-309] - Human Testis (formalin-fixed, paraffin-embedded) stained with ATM antibody (2C1) [NB100-309] at 5 ug/ml followed by biotinylated anti-mouse IgG secondary more
Western Blot: ATM Antibody (2C1) [NB100-309] - Detection of human ATM protein using ATM antibody (2C1) [NB100-309] by western blot or immunoprecipitation. Theoretical molecular weight 351 kDa.
Immunohistochemistry-Paraffin: ATM Antibody (2C1) [NB100-309] - Human breast carcinoma. ATM stained by ATM antibody [2C1] diluted at 1:100.Antigen Retrieval: Citrate buffer, pH 6.0, 15 min.
Western Blot: ATM Antibody (2C1) [NB100-309] - Analysis of ATM in U2OS sarcoma cells using ATM antibody (2C1) [NB100-309]. Theoretical molecular weight 351 kDa. Western blot image submitted by a verifeid customer review.
Western Blot: ATM Antibody (2C1) [NB100-309] - Whole cell extract (30 ug) was separated by 5% SDS-PAGE, and the membrane was blotted with ATM antibody (2C1) [NB100-309] diluted at 1:1000. Theoretical molecular weight more
Immunohistochemistry-Paraffin: ATM Antibody (2C1) [NB100-309] - Human Kidney (formalin-fixed, paraffin-embedded) stained with ATM antibody (2C1) [NB100-309] at 5 ug/ml followed by biotinylated anti-mouse IgG secondary more
Knockdown Validated: ATM Antibody (2C1) [NB100-309] - Non-transfected (-) and transfected (+) HeLa whole cell extracts (60 ug) were separated by 5% SDS-PAGE, and the membrane was blotted with ATM antibody (2C1) more
Genetic Strategies: Knockdown Validated: ATM Antibody (2C1) [NB100-309] - Methylated EDSBs may be repaired by an ATM-dependent pathway. Immunoblots of ATM and DNA-PKcs in ATM shRNA-transfected HeLa cells, using more
Immunoprecipitation: ATM Antibody (2C1) [NB100-309] - MDA-MB-231 whole cell lysates were immunoprecipitated with 2 ug ATM Antibody (NB100-309), followed by Western blot (primary antibody: NB100-309 at 1:1000, 4C more

Product Details

Reactivity Hu, Mu, Rt, PmSpecies Glossary
Applications WB, ChIP, ELISA, Flow, ICC/IF, IHC, IHC-P, IP, KD, Single-Cell Western
Validated by:

Genetic Strategies


Order Details

ATM Antibody (2C1) Summary

ATM Antibody (2C1) was made to a recombinant protein expressed in E. coli corresponding to amino acids 2577-3056.
Nucleus. Cytoplasmic vesicle.
ATM Antibody (2C1) recognizes full-length ATM, a 350-kDa nuclear phosphoprotein.
Antigen Affinity-purified
Innovator's Reward
Test in a species/application not listed above to receive a full credit towards a future purchase.


  • Western Blot 1:500 - 1:3000
  • Chromatin Immunoprecipitation 1:10 - 1:500
  • ELISA 1:100 - 1:2000
  • Flow Cytometry
  • Immunocytochemistry/Immunofluorescence 1:10 - 1:500
  • Immunohistochemistry 5 ug/mL
  • Immunohistochemistry-Paraffin 5 ug/mL
  • Immunoprecipitation 1 - 10 ug/mL
  • Knockdown Validated
  • Single Cell Western 100 ug/mL
Application Notes
Use in IHC-P reported in scientific literature (PMID: 25895060). Use in FLOW reported in scientific literature (PMID: 15197179). ATM antibody is validated for WB, IP from a verified customer reviews.
Theoretical MW
351 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Reviewed Applications
Read 3 Reviews rated 4.7
NB100-309 in the following applications:

Read Publications using
NB100-309 in the following applications:

Reactivity Notes

Use in Human reported in scientific literature (PMID:33743824).

Packaging, Storage & Formulations

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
No Preservative
Antigen Affinity-purified

Alternate Names for ATM Antibody (2C1)

  • AT mutated
  • A-T mutated
  • AT1
  • ATA
  • ataxia telangiectasia mutated (includes complementation groups A, C and D)
  • ataxia telangiectasia mutated
  • ATC
  • ATD
  • ATDC
  • ATE
  • ATM serine/threonine kinase
  • ATM
  • DKFZp781A0353
  • EC
  • MGC74674
  • serine-protein kinase ATM
  • TEL1
  • TEL1, telomere maintenance 1, homolog
  • TELO1
  • TPLL


ATM (ataxia telangiectasia mutated kinase) is the master regulator of the DNA double-strand break (DSB) repair pathway. This ubiquitously expressed serine/threonine protein kinase belongs to the PI3K-like family of proteins and responds to DSBs caused by oxidative and other genotoxic stresses (1). In addition to regulating the DNA damage response, ATM participates in vesicle and protein transport, T-cell development, gonads/neurological function, pre-B cell allelic exclusion, cell cycle control, and acts as a tumor suppressor (2,3). Defects in ATM are associated with ataxia telangiectasia (AT), T-cell acute lymphoblastic leukemia (TALL), T-prolymphocytic leukemia (TPLL), and B-cell non-Hodgkin lymphomas (BNHL) including mantle cell lymphoma (MCL) and B-cell chronic lymphocytic leukemia (BCLL) (4).

The theoretical molecular weight of ATM is 350 kDa and it has 3 main domains: a FAT (focal adhesion targeting) domain (aa 1960-2566), a PI-3/PI-4 kinase catalytic domain (aa 2712-2962), and a C-terminal FAT domain (aa 3024-3056). ATM exists as a dimer or tetramer in its inactive state. Upon sensing DNA damage, the MRE11-RAD50-NBS1 (MRN) complex recruits ATM. The intricate process of ATM activation involves acetylation by KAT5/TIP60, autophosphorylation at Ser-1981, and dissociation into catalytically active monomers (5). Following activation, ATM phosphorylates multiple substrates such as p53/TP53 and Chk2 involved in DNA repair, checkpoint signaling, and the apoptosis pathway.


1. Paull TT. (2015) Mechanisms of ATM Activation. Annu Rev Biochem. 84:711-38. PMID: 25580527

2. Chaudhary MW and Al-Baradie RS. (2014) Ataxia-telangiectasia: future prospects. Appl Clin Genet. 7:159-167. PMID: 25258552

3. Stagni V, Cirotti C, and Barila D. (2018) Ataxia-Telangiectasia Mutated Kinase in the Control of Oxidative Stress, Mitochondria, and Autophagy in Cancer: A Maestro With a Large Orchestra. Front Oncol. 8:73. PMID: 29616191

4. Gumy-Pause F, Wacker P, and Sappino AP. (2004) ATM gene and lymphoid malignancies. Leukemia. 18(2):238-42. PMID: 14628072

5. Adamowicz M. (2018) Breaking up with ATM. J Immunol Sci. 2(1):26-31. PMID: 29652413


This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
