PRDM16/MEL1 Antibody [Unconjugated]


Western blot shows lysates of K562 human chronic myelogenous leukemia cell line. PVDF Membrane was probed with 1 µg/mL of Sheep Anti-Human/Mouse PRDM16 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6295) more
PRDM16 was detected in immersion fixed frozen sections of mouse embryo (E13.5) using Sheep Anti-Human/Mouse PRDM16 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6295) at 10 µg/mL overnight at 4 °C. Tissue more

Product Details

Reactivity Hu, MuSpecies Glossary
Applications WB, IHC

Order Details

View Available Formulations
Catalog# & Formulation Size Price

PRDM16/MEL1 Antibody [Unconjugated] Summary

E. coli-derived recombinant mouse PRDM16
Accession # A2A935.1
Detects mouse and human PRDM16 in direct ELISAs and Western blots.
Purity Statement
Antigen Affinity-purified
Innovator's Reward
Test in a species/application not listed above to receive a full credit towards a future purchase.


  • Western Blot 1 ug/mL
  • Immunohistochemistry 5-15 ug/mL
Read Publications using
AF6295 in the following applications:

Packaging, Storage & Formulations

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.
No Preservative
Reconstitution Instructions
Sterile PBS to a final concentration of 0.2 mg/mL.


This product is produced by and ships from R&D Systems, Inc., a Bio-Techne brand.

Alternate Names for PRDM16/MEL1 Antibody [Unconjugated]

  • MDS1/EVI1-like gene 1
  • MEL1
  • MEL1KIAA1675PFM13MGC166915
  • PFM13
  • PR domain containing 16
  • PR domain zinc finger protein 16
  • PR domain-containing protein 16
  • PRDM16
  • Transcription factor MEL1


PRDM16 (PR [PRDI-BF1 and RIZ] domain containing protein 16; also MEL-1) is a 170 kDa member of the PR Domain family of proteins. It is a transcriptional regulator expressed in the embryo, and is reported to participate in the maintenance of both neuronal and hematopoietic progenitor stem cells populations, and to preferentially promote the development of brown fat from adipomyocyte precursors. The generation of brown fat is likely due to suppression of muscle-specific factors. Mouse PRDM16 is 1275 amino acids (aa) in length. It contains one SET domain (aa 85-208) followed by ten C2H2 type Zn finger motifs (aa 230-1030). There are multiple potential isoform variants that likely vary from 150-170 kDa in size. One isoform shows a deletion of aa 1232-1250, a second isoform shows a three aa substitution for aa 1174-1275, and a third isoform possesses an alternative start site at Met21, coupled to a deletion of aa 1196-1133. Over aa 537-688, mouse PRDM16 shares 81% and 95% aa identity with human and rat PRDM16, respectively.


This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
