Recombinant Mouse BMP-4 Protein, CF


There are currently no images for BMP-4 (5020-BP/CF).

Every product we sell is backed by Novus' 100% Guarantee. If you have used this product, please submit your images and reviews to earn reward points.

Product Details

Reactivity MuSpecies Glossary
Applications Bioactivity

Order Details

View Available Formulations
Catalog# & Formulation Size Price

Recombinant Mouse BMP-4 Protein, CF Summary

Details of Functionality
Measured by its ability to induce alkaline phosphatase production by ATDC5 mouse chondrogenic cells. Nakamura, K. et al. (1999) Exp. Cell Res. 250:351. The ED50 for this effect is 2-12 ng/mL.
Chinese Hamster Ovary cell line, CHO-derived mouse BMP-4 protein
Accession #
N-terminal Sequence
Structure / Form
Disulfide-linked homodimer
Protein/Peptide Type
Recombinant Proteins
>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining
Endotoxin Note
<0.01 EU per 1 μg of the protein by the LAL method.


Theoretical MW
13.1 kDa (monomer).
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
18-26 kDa, reducing conditions
Read Publications using
5020-BP/CF in the following applications:

Packaging, Storage & Formulations

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 3 months, -20 to -70 °C under sterile conditions after reconstitution.
Lyophilized from a 0.2 μm filtered solution in Acetonitrile and TFA.
>95%, by SDS-PAGE visualized with Silver Staining and quantitative densitometry by Coomassie® Blue Staining
Reconstitution Instructions
Reconstitute at 100 μg/mL in 4 mM HCl.


This product is produced by and ships from R&D Systems, Inc., a Bio-Techne brand.

Alternate Names for Recombinant Mouse BMP-4 Protein, CF

  • BMP-2B
  • BMP2B1
  • BMP4
  • BMP-4
  • Bone morphogenetic protein 2B
  • bone morphogenetic protein 4
  • DVR4
  • OFC11
  • ZYME


BMP-4 is a TGF-beta superfamily ligand that is widely expressed from early embryogenesis through adulthood. It plays an important role in mesenchyme formation, epidermal determination, suppression of neural induction, the development of multiple organs, and tissue repair (1-5). The mouse BMP-4 precursor contains a 273 amino acid (aa) propeptide and a 116 aa mature protein (6). The propeptide is cleaved intracellularly by furin or proprotein convertase 6, enabling the 15 kDa mature BMP-4 monomer to form an active disulfide linked homodimer or heterodimer with BMP-7 (7-9). Mature mouse and human BMP-4 share 98% aa sequence identity. Mouse BMP-4 shares 85% aa sequence identity with mouse BMP-2 and 35%-54% with other mouse BMPs. Compared to BMP-4 homodimers, BMP-4/BMP-7 heterodimers exhibit a greater potency in inducing osteogenic differentiation (9). In Xenopus, the heterodimers can also induce the formation of mesoderm, whereas BMP-4 homodimers only provide ventralizing signals for existing mesoderm (10). BMP-4 signals through tetrameric complexes composed of type I (primarily Activin RIA or BMPR-IA) and type II (primarily Activin RIIA or BMPR-II) receptors (11, 12). The bioavailability of BMP-4 is regulated by its interaction with multiple proteins and glycosaminoglycans (13-15).

  1. Zhang, P. et al. (2008) Blood 111:1933.
  2. Gambaro, K. et al. (2006) Cell Death Differ. 13:1075.
  3. Simic, P. and S. Vukicevic (2005) Cytokine Growth Factor Rev. 16:299.
  4. Sadlon, T.J. et al. (2004) Stem Cells 22:457.
  5. Frank, D.B. et al. (2005) Circ. Res. 97:496.
  6. Oida, S. et al. (1995) DNA Seq. 5:273.
  7. Cui, Y. et al. (1998) EMBO J. 17:4735.
  8. Cui, Y. et al. (2001) Genes Dev. 15:2797.
  9. Aono, A. et al. (1995) Biochem. Biophys. Res. Commun. 210:670.
  10. Nishimatsu, S. and G.H. Thomsen (1998) Mech. Dev. 74:75.
  11. Chen, D. et al. (2004) Growth Factors 22:233.
  12. Lavery, K. et al. (2008) J. Biol. Chem. April 24 epub.
  13. Rosen, V. (2006) Ann. N.Y. Acad. Sci. 1068:19.
  14. Jones, C.M. and J.C. Smith (1998) Dev. Biol. 194:12.
  15. Takada, T. et al. (2003) J. Biol. Chem. 278:43229.
