PDGF R beta [p Tyr740] Antibody (SN0646)

Immunocytochemistry/Immunofluorescence: PDGF R beta [p Tyr740] Antibody (SN0646) [NBP2-67665] - Staining PDGF Receptor beta(phospho Y740) in L6 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunocytochemistry/Immunofluorescence: PDGF R beta [p Tyr740] Antibody (SN0646) [NBP2-67665] - Staining PDGF Receptor beta(phospho Y740) in Hela cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunocytochemistry/Immunofluorescence: PDGF R beta [p Tyr740] Antibody (SN0646) [NBP2-67665] - Staining PDGF Receptor beta(phospho Y740) in C2C12 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Product Discontinued

PDGF R beta [p Tyr740] Antibody (SN0646) Summary

• Additional Information: Recombinant Monoclonal Antibody.
• Immunogen: Synthetic phospho-peptide corresponding to residues surrounding Tyr740 of human PDGF R beta. (SwissProt: P09619 Human; SwissProt: P05622 Mouse; SwissProt: Q05030 Rat)
• Modification: p Tyr740
• Localization: Cell membrane, Cytoplasmic vesicle.
• Isotype: IgG
• Clonality: Monoclonal
• Host: Rabbit
• Gene: PDGFRB
• Purity: Protein A purified

Applications/Dilutions

• Dilutions:
  • Immunocytochemistry/ Immunofluorescence 1:50-1:200
  • Western Blot 1:1000

Packaging, Storage & Formulations

• Storage: Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
• Buffer: TBS (pH7.4), 0.05% BSA, 40% Glycerol
• Preservative: 0.05% Sodium Azide
• Concentration: 1 mg/ml
• Purity: Protein A purified

Alternate Names for PDGF R beta [p Tyr740] Antibody (SN0646)

• beta-type platelet-derived growth factor receptor
• CD140 antigen-like family member B
• CD140b antigen
• CD140b
• EC 2.7.10
• EC 2.7.10.1
• JTK12
• PDGF R beta
• PDGFR
• PDGFR1
• PDGFRB
• PDGF-R-beta
• platelet-derived growth factor receptor, beta polypeptide

Background

Human platelet-derived growth factor (PDGF) receptor, is a receptor tyrosine kinase whose activity induces various signalling cascades leading to cell growth and proliferation. Two major isoforms exist, PDGF receptor-alpha and PDGF receptor-beta. PDGF receptor-beta can only bind two specific PDGF isoforms, PDGF-beta and PDGF-delta (1,2). Upon ligand binding, the receptor undergoes autophosphorylation, allowing binding and activation of cytoplasmic SH2 domain-containing signal transduction molecules such as PI kinase (3), Grb2, and Src, among others.

Limitations

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Bioinformatics

• Gene Symbol: PDGFRB
