MAGI2 Antibody

Western blot shows lysates of human brain (cortex) tissue. PVDF membrane was probed with 1 µg/mL of Goat Anti-Human MAGI2 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF7117) followed by HRP-conjugated Anti-Goat IgG Secondary Antibody (Catalog # HAF019). A specific band was detected for MAGI2 at approximately 170 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.

MAGI2 was detected in immersion fixed U-87 MG human glioblastoma/ astrocytoma cell line using Goat Anti-Human MAGI2 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF7117) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Goat IgG Secondary Antibody (red; Catalog # NL001) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm. View our protocol for Fluorescent ICC Staining of Cells on Coverslips.

MAGI2 was detected in immersion fixed paraffin-embedded sections of human brain (hippocampus) using Goat Anti-Human MAGI2 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF7117) at 15 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). Specific staining was localized to synaptic boutons and neuronal processes. View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.

• Reactivity: Hu, Mu
• Applications: WB, IHC, ICC/IF
• Clonality: Polyclonal
• Host: Goat
• Conjugate: Unconjugated
• Concentration: LYOPH

MAGI2 Antibody Summary

• Immunogen: E. coli-derived recombinant human MAGI2
  Ser2-Arg130
  Accession # Q86UL8
• Specificity: Detects human MAGI2 in direct ELISAs and Western blots. In direct ELISAs, less than 1% cross-reactivity with recombinant ARIP-2 is observed.
• Source: N/A
• Isotype: IgG
• Clonality: Polyclonal
• Host: Goat
• Gene: MAGI2
• Purity Statement: Antigen Affinity-purified

Applications/Dilutions

• Dilutions:
  • Immunocytochemistry 5-15 ug/mL
  • Immunohistochemistry 5-15 ug/mL
  • Western Blot 1 ug/mL

Packaging, Storage & Formulations

• Storage: Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  12 months from date of receipt, -20 to -70 degreesC as supplied. 1 month, 2 to 8 degreesC under sterile conditions after reconstitution. 6 months, -20 to -70 degreesC under sterile conditions after reconstitution.
• Buffer: Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
• Preservative: No Preservative
• Concentration: LYOPH
• Reconstitution Instructions: Sterile PBS to a final concentration of 0.2 mg/mL.

Notes

This product is produced by and ships from R&D Systems, Inc., a Bio-Techne brand.

Alternate Names for MAGI2 Antibody

• ACVRINP1
• ACVRIP1
• AIP1
• AIP1AIP-1
• ARIP1
• atrophin 1 interacting protein 1
• atrophin-1 interacting protein A
• Atrophin-1-interacting protein 1
• Atrophin-1-interacting protein A
• KIAA0705activin receptor interacting protein 1
• MAGI2
• MAGI-2SSCAM
• membrane associated guanylate kinase, WW and PDZ domain containing 2
• Membrane-associated guanylate kinase inverted 2
• membrane-associated guanylate kinase, WW and PDZ domain-containing protein 2
• SSCAM

Background

MAGI2 (AIP-1, ACVRINP1 also known as Activin receptor-interacting protein 1 and S-SCAM in rodents); is a 160-180 kDa member of the MAGUK family of proteins. It is found in neuronal post-synaptic membrane complexes, and serves as a molecular scaffold for multiple proteins, including alpha -actinin, dendrin, SMAD3 and beta -catenin. ARIP-1 facilitates the signaling of both growth factor and neurotransmitter receptors such as ActRIIA, NMDA and beta 1 -adrenergic receptors. Human ARIP-1 is 1455 amino acids (aa) in length. It contains an N-terminal PZD domain (aa 17-101), followed by a guanylate kinase-like domain (aa 109-283), two WW domains (aa 302-381) and five subsequent PZD domains (aa 426-1229). ARIP-1 is reported to dimerize/oligomerize. There are three potential isoform variants. All utilize an alternative start site at Met164 that may be accompanied by either an Arg substitution for aa 757-771, or a 48 aa substitution for aa 1236-1455. Over aa 2-130, human and mouse ARIP-1 are identical in aa sequence.

Limitations

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Publications for MAGI2 Antibody (AF7117)(1)

Publication using AF7117

• Z Zuo, JX Shen, Y Pan, J Pu, YG Li, XH Shao, WP Wang Weighted Gene Correlation Network Analysis (WGCNA) Detected Loss of MAGI2 Promotes Chronic Kidney Disease (CKD) by Podocyte Damage Cell. Physiol. Biochem., 2018-11-16;51(1):244-261. 2018-11-16 [PMID: 30448842] (Western Blot, Mouse)

Bioinformatics

• Gene Symbol: MAGI2
• Uniprot:
  • Q86UL8(Human)
